Paslanmaz Çelik Profil
Kare Profil Ağırlıkları | ||||||||||||
ÖLÇÜ | ÖLÇÜ | 1mm | 1,2mm | 1,5mm | 2mm | 2,5mm | 3mm | 4mm | 5mm | 6mm | ||
12 | 12 | 0,358 | ||||||||||
15 | 15 | 0,453 | 0,538 | 0,661 | ||||||||
16 | 16 | 0,485 | 0,576 | 0,709 | ||||||||
19 | 19 | 0,567 | 0,675 | 0,832 | 1,09 | |||||||
20 | 20 | 0,613 | 0,729 | 0,901 | 1,176 | |||||||
22 | 22 | 0,677 | 0,806 | 0,996 | 1,303 | |||||||
25 | 25 | 0,772 | 0,921 | 1,14 | 1,495 | 1,837 | 2,167 | |||||
30 | 30 | 0,932 | 1,112 | 1,379 | 1,814 | 2,236 | 2,645 | |||||
32 | 32 | 0,96 | 1,15 | 1,42 | 1,87 | 2,31 | 2,74 | |||||
35 | 35 | 1,091 | 1,304 | 1,618 | 2,133 | 2,635 | 3,124 | |||||
40 | 40 | 1,251 | 1,495 | 1,858 | 2,452 | 3,033 | 3,602 | 4,703 | ||||
45 | 45 | 1,41 | 1,686 | 2,097 | 2,771 | 3,432 | 4,081 | |||||
50 | 50 | 1,878 | 2,336 | 3,09 | 3,831 | 4,559 | 5,979 | 7,349 | ||||
60 | 60 | 2,814 | 3,728 | 4,628 | 5,516 | 7,255 | 8,943 | |||||
70 | 70 | 3,293 | 4,366 | 5,426 | 6,473 | 8,531 | 10,538 | |||||
80 | 80 | 3,771 | 5,004 | 6,223 | 7,43 | 9,807 | 12,133 | 14,41 | ||||
100 | 100 | 4,728 | 6,279 | 7,818 | 9,344 | 12,359 | 15,323 | 18,237 | ||||
120 | 120 | 7,555 | 9,413 | 11,258 | 14,91 | 18,513 | 22,065 | |||||
140 | 140 | 8,831 | 11,008 | 13,172 | 17,462 | 21,703 | 25,893 | |||||
150 | 150 | 9,469 | 11,805 | 14,129 | 18,738 | 23,298 | 27,807 | |||||
200 | 200 | 12,659 | 15,793 | 18,913 | 25,118 | 31,272 | 37,376 | |||||
Dikdörtgen Profil Ağırlıkları | ||||||||||||
ÖLÇÜ | ÖLÇÜ | 1mm | 1,2mm | 1,5mm | 2mm | 2,5mm | 3mm | 4mm | 5mm | 6mm | ||
15 | 10 | 0,37 | 0,44 | 0,54 | ||||||||
20 | 10 | 0,453 | 0,538 | 0,661 | ||||||||
20 | 15 | 0,533 | 0,634 | 0,781 | 1,016 | |||||||
25 | 10 | 0,533 | 0,634 | 0,781 | ||||||||
25 | 15 | 0,613 | 0,729 | 0,901 | 1,176 | |||||||
25 | 20 | 0,693 | 0,825 | 1,02 | 1,335 | |||||||
30 | 10 | 0,613 | 0,729 | 0,901 | 1,176 | |||||||
30 | 15 | 0,693 | 0,825 | 1,02 | 1,335 | |||||||
30 | 20 | 0,772 | 0,921 | 1,14 | 1,495 | 1,837 | 2,167 | |||||
30 | 25 | 0,84 | 1 | 1,24 | 1,63 | |||||||
35 | 15 | 0,76 | 0,91 | 1,13 | 1,48 | |||||||
35 | 20 | 0,852 | 1,017 | 1,259 | 1,654 | 2,036 | 2,406 | |||||
40 | 10 | 0,76 | 0,91 | 1,13 | 1,48 | |||||||
40 | 15 | 0,852 | 1,017 | 1,259 | 1,654 | 2,036 | 2,406 | |||||
40 | 20 | 0,932 | 1,112 | 1,379 | 1,814 | 2,236 | 2,645 | |||||
40 | 27 | 1,044 | 1,246 | 1,547 | 2,037 | 2,515 | 2,98 | |||||
40 | 30 | 1,091 | 1,304 | 1,618 | 2,133 | 2,635 | 3,124 | |||||
45 | 15 | 0,91 | 1,09 | 1,35 | 1,78 | |||||||
45 | 20 | 0,99 | 1,18 | 1,46 | 1,92 | |||||||
50 | 10 | 0,91 | 1,09 | 1,35 | 1,78 | |||||||
50 | 20 | 1,091 | 1,304 | 1,618 | 2,133 | 2,635 | 3,124 | |||||
50 | 25 | 1,171 | 1,399 | 1,738 | 2,292 | 2,834 | 3,363 | |||||
50 | 30 | 1,251 | 1,495 | 1,858 | 2,452 | 3,033 | 3,602 | |||||
50 | 40 | 1,41 | 1,686 | 2,097 | 2,771 | 3,432 | 4,081 | |||||
60 | 20 | 1,251 | 1,495 | 1,858 | 2,452 | 3,033 | 3,602 | |||||
60 | 30 | 1,41 | 1,686 | 2,097 | 2,771 | 3,432 | 4,081 | |||||
60 | 40 | 1,878 | 2,336 | 3,09 | 3,831 | 4,559 | 5,979 | |||||
70 | 20 | 1,65 | 2,05 | 2,71 | 3,36 | 4 | ||||||
70 | 30 | 2,29 | 3,03 | 3,76 | 4,48 | |||||||
70 | 40 | 2,575 | 3,409 | 4,229 | 5,038 | |||||||
80 | 20 | 2,29 | 3,03 | 3,76 | 4,48 | |||||||
80 | 30 | 2,53 | 3,35 | 4,16 | 4,96 | |||||||
80 | 40 | 2,814 | 3,728 | 4,628 | 5,516 | 7,255 | 8,943 | 10,582 | ||||
80 | 50 | 3,01 | 4 | 4,96 | 5,92 | 7,79 | 9,62 | 11,39 | ||||
80 | 60 | 3,293 | 4,366 | 5,426 | 6,473 | 8,531 | 10,538 | 12,496 | ||||
100 | 20 | 2,76 | 3,65 | 4,54 | 5,41 | |||||||
100 | 30 | 3,01 | 4 | 4,96 | 5,92 | |||||||
100 | 40 | 3,293 | 4,366 | 5,426 | 6,473 | 8,531 | 10,538 | 12,496 | ||||
100 | 50 | 3,532 | 4,685 | 5,824 | 6,952 | 9,169 | 11,336 | 13,453 | ||||
100 | 60 | 3,771 | 5,004 | 6,223 | 7,43 | 9,807 | 12,133 | 14,41 | ||||
100 | 80 | 4,25 | 5,641 | 7,021 | 8,387 | 11,083 | 13,728 | 16,324 | ||||
120 | 40 | 3,771 | 5,004 | 6,223 | 7,43 | 9,807 | 12,133 | 14,41 | ||||
120 | 60 | 4,25 | 5,641 | 7,021 | 8,387 | 11,083 | 13,728 | 16,324 | ||||
120 | 80 | 4,728 | 6,279 | 7,818 | 9,344 | 12,359 | 15,323 | 18,237 | ||||
140 | 80 | 10,301 | 13,635 | 16,918 | 20,151 | |||||||
150 | 50 | 9,344 | 12,359 | 15,323 | 18,237 | |||||||
150 | 100 | 11,736 | 15,548 | 19,31 | 23,022 | |||||||
160 | 80 | 11,258 | 14,91 | 18,513 | 22,065 | |||||||
200 | 100 | 14,129 | 18,738 | 23,298 | 27,807 |
